GOLDLINE WOOD Acoustic Panels for Walls and Ceiling

The interior architecture generates the first impression through designed surfaces that require acoustical performance to make those spaces and environments more expressive both visual and acoustical comfort in interior spaces.

We carefully coordinate refined design features in a room to produce the optimum design from an aesthetic and acoustic comfort. We use high quality materials in our paneling / cladding system and can produce them according to specific customer requirements. Filled with innovative ideas we create perfect solutions that are both artistic and provide acoustical comfort.



Timeless design and excellent absorption values characterize the GOLDLINE WOOD ACOUSTIK PRO Panels in three superposed layers of transverse and longitudinal slits generate an excellent perforation pattern. The tongue and groove system, the panels can be strung together unlimitedly. The result is a seamless and light looking design of your wall and ceiling paneling / cladding.

GOLDLINE WOOD ACOUSTIK PRO

Wood is one of the oldest materials in the world. With its incomparable and unique variety this mature NATURAL material offers inexhaustible expressing possibilities to be extensively creative. Application of advanced technology and acoustic theory the GOLDLINE WOOD ACOUSTIK PRO offer wide range of timber, polyester and magnesia composite materials options. These panels are visually attractive offering natural veneers, engineered and designer veneers, textures, colors, decorative effects, melamine and RAL paint finishes and expressions.

RANGE OF ACOUSTIC WOOD PANELS HAVE BEEN DEVELOPED. THESE ACOUSTIC WOOD PANELS ARE VISUALLY ATTRACTIVE DUE TO THE BEAUTY OF WOOD VENEERS, LAMINATES AND RAL COLORS AS WELL AS BEING EASY TO INSTALL. THE ACOUSTIC WOOD PANELS DECORATE AS WELL AS PROVIDE A SOLUTION TO REVERBERATE NOISE LEVELS INSIDE BUILDINGS. SINCE WOOD IS A PRODUCT OF NATURE, THE WOOD ACOUSTIK PRO RANGE OF ACOUSTIC WOOD PANELS CREATES A NATURALLY AESTHETIC SOLUTION TO NOISE CONTROL.

Applications

GOLDLINE Acoustic Wood Panels for Walls and Ceiling

are the Premium Solutions for Luxury Interior Design and Controlling Ambient Reverberated Noises and Sound Transmission for:

  • Entertainment
  • Educational
  • Healthcare
  • Offices / Commercial Spaces
  • Music Recording and Broadcasting Studios
  • Auditoriums, Cinemas & Theaters
  • Conference and Meeting Areas
  • Recreational and Fitness Places
  • Multimedia Presentation Environments
  • Homes and every area where sound matter

Possibilities

Limitless branding and design possibilities with in-house custom cutting and size customization.

GOLDLINE WOOD ACOUSTIK PRO

GOLDLINE WOOD ACOUSTIK PRO – WOOD ACOUSTICAL PANELS / WALL CLADDING / CEILING

Product Specifications

Properties:

Fire Rating

Class A NFPA 101 Life Safety Code

Fire Test Certified

ASTM E84-90A Equivalent to NFPA No. 255 and UL No. 723

Flame Spread Index

0 – 25 Flame Spread Index

Edges

Thermal Bonded in a Non-Woven Matrix

Fungi Resistance Certified

ASTM C 1338 – 08

Smoke Developed Index values

0 – 450 Smoke Developed Index

LEED Rating

MER V 4.1 Rating

Acoustic Backing

Black Fleece and Sound Absorption as Optional

Finishes

REAL NATURAL WOOD VENEERS, MELAMINES ENGINEERED VENEERS, ALPI VENEERS, LAMINATES & RAL PAINTS

Materials

HIGH DENSITY MDF / REAL NATURAL WOOD VENEERS, MELAMINES ENGINEERED VENEERS, ALPI VENEERS, LAMINATES & RAL PAINTS

Design Types & Modules

MICRO PERFORATED, PERFORATED and LONGITUDINAL GROOVES n STRIP DESIGNS

Material Colors Available

BLACK, BEIGE, DARK BLUE, WHITE and GREY, BURGUNDY AND OTHERS ON REQUESTS AND SPECIAL ORDERS

Sound Absorption Certified

ASTM C423-09A

Absorption Coefficient

1.00 and 1.01@ 5000 Hz

NRC

0.70 and 0.95

Density

From 450Kg/m³ to 650Kg/m³

Thicknesses

12mm, 15mm and 18mm

Dimensions

1200 x 2400mm

Installation

Any Smooth Surface

Mechanical Installation

GOLDLINE Anchor System

Components

Polyester Resin

CAS NO.

68604-67-1

Percent Range

90-95%

OSHA regulations

NOT hazardous according OHSA29CFR1910.1200

HMIS Ratings

Health 0 Flammability 0 Reactivity 0

Primary Route of Exposure

None

Eye contact

No adverse effects expected

Skin Contact

No adverse effects expected

Inhalation

No adverse effects expected

Ingestion

No adverse effects expected

Medical Conditions Aggravated by Exposure

None expected

PHYSICAL AND CHEMICAL PROPERTIES

GOLDLINE POLYESTER SOUND ABSORPTION ACOUSTICAL SYSTEM

ODOR

None

Physical state

Solid

Vapor Pressure

None

Vapor Density(air-1)

Not Applicable

pH

Not Applicable

DOT Corrosivity

Not Applicable

Percent Volatile by Volume

<1%

VOC- Volatile Organic Content

<1%

Molecular Weight

Not Applicable

Boiling Point

Not Applicable

Melting Point

220C

Specific Gravity

>1.0

Average Carbon Number

Not Applicable

Viscosity@100F

Not Applicable

Viscosity@40C

Not Applicable

Pour Point

Not Applicable

Solubility in water

Not Soluble

Octanol/Water Coefficient

None

Chemical Stability

Stable

Conditions to Avoid

None

Incompatible Materials to Avoid

None

Hazards in Blend:

Not Hazardous

Complementary Products

GOLDLINE WOOD ACOUSTIC PRO MICRO PERFORATED PANELS

GOLDLINE WOOD ACOUSTIC PRO GROOVE N STRIP

GOLDLINE WOOD ACOUSTIC PRO PERFORATED PANELS
